Delivery fleets
DigiStreamView is the operating system that runs a digital advertising business on moving vehicles. On delivery motorbikes it manages three-sided LED boxes with 4G and GPS, so you can schedule campaigns, follow each bike and report on every screen from one cloud platform.
It is a box mounted on the back of a delivery motorbike with a display on three sides. The screens show advertising while the rider moves through the city, and a controller card inside the box connects to DigiStreamView over 4G.
Content is visible to traffic and pedestrians from behind and from both sides of the bike.
Each box reports its location and receives content updates over a 4G connection, with no manual file changes.
Upload creatives, schedule and target campaigns, and review reports from the same platform you use for other vehicles and screens.
DigiStreamView controls the screens in the box. Campaigns can be scheduled by time and targeted by area with geo-fencing, and GPS location from each bike supports reporting.
Add creatives to the platform and set when and where they should play.
Use geo-fencing so content changes as a bike enters or leaves a zone you define.
Follow bike locations and review campaign reports from the web platform.
These are typical figures for a three-sided delivery box. Delivery boxes come from several manufacturers and the exact specification depends on the configuration you choose, so we confirm the details for your fleet when you enquire.
| Item | General specification |
|---|---|
| Display sides | Three (left, right and rear) |
| Pixel pitch and resolution | P2.5, 128 x 128 pixels per side (P3 also available) |
| Screen size per side | About 15 in (384 x 384 mm); smaller variants from 320 mm |
| Box dimensions | About 500 x 500 x 530 mm |
| Weight | About 16 kg |
| Brightness | Up to about 4,500 nit for outdoor daylight use |
| Housing | Heat-resistant FRP housing with an IP65 weatherproof rating (typical) |
| Power input | DC 9 to 36 V; typical average draw about 66 to 150 W |
| Battery | Typical runtime of 6 to 8 hours where a battery is fitted |
| Connectivity | 4G (SIM card), WiFi, LAN and USB, with a GPS module for location tracking |
| Controller cards | Xixun or Sysolutions controller cards; Android-based control where available |
| Mounting | Fits to the motorcycle with a mounting kit and basic hand tools |
| Operating temperature | About -40 to +75 degrees C |
| Content | Video, images, text and animation, scheduled from the DigiStreamView cloud platform |
| Applications | Motorcycles, e-bikes and scooters in food delivery, takeaway and express delivery fleets |
General figures for reference only. They are not a product specification and vary with the box and configuration selected.
